The control system of Porta Deslizante Automatica contains basic function and extensional function. There are 4 working mode(automatic /hold-open/lock/half-open)could be chosen by operators with function keypad or switch to meet different needs.
|
Door style |
Single-opening |
Double-opening |
|
Door leaf weight |
≤1*150 kg |
≤2*140 kg |
|
Door leaf width |
600-1200mm |
500-1150mm |
|
Opening speed |
150-450mm/s(Adjustable) |
|
|
Closing speed |
100-430mm/s(Adjustable) |
|
|
Motor |
24V 60W brushless DC motor |
|
|
Opening time |
0-9second(Adjustable) |
|
|
Impact function |
Rebounding up on impact |
|
|
Voltage |
AC220V 50Hz-60Hz |
|
|
Operating Temperature |
-20°C~60°C |
|
**Good solution for accessories, for example, finger printer, remote control, push button, access keypad, security sensor, fire alarm, digital wireless video entry and so on.
**Optional backup battery can ensure the normal operation in case of the power failure.
**Can be interfaced with security systems and different types of locking systems.
** In case of power failure, all of the programmed parameters remain in the computers memory, if the door is not locked the door can be operated manually.
